The Ghibli R90 ensures efficiency, reliability, and consistency. Aiming to maximize your coffee's flavor and aroma while optimizing extractable properties. This advanced roaster uses our in-house exclusive, technology to save energy and reduce your gas emissions. We made the perfect roaster for your industrial coffee business needs.
Swift, responsive pneumatic doors quickly load the drum or release the roasted beans.
Precisely monitor in-drum pressure to ensure consistent results and smooth operation.
Built with precision metalwork, and premium hardware for best reliability.
Safe manual drum rotation during power shortages
Necessary safety measure in an extreme event of fire inside the drum.
Intuitive touch screen interface for smooth, responsive control
Precise Green Coffee Loader with a built-in scale
Multi method cooling system for quick and uniform cooling
Perfect heat dispersion assures essential coffee compounds are fully developed and enhanced during the roasting process.
A unique combination of conduction and controlled convection assures the final cup profile displays excellent, high aroma levels.
Advanced thermodynamic design and a clean, precise combustion method secure a high-quality, smooth cup profile.
Engineered for high-output performance with minimal power consumption, ensuring maximum energy savings and a reduced carbon footprint.
Batch Capacity
30 - 90 kg (66 - 199 lbs) of Green Coffee
Roasting Cycle
16-18 minutes for a full batch
Hourly Output
Approx. 270kg (595 lbs)
Quality and safety compliance
CE, RoHS, EMC
Electrical Specifications
3x230/3x110V | 11,000W | incl. Loader, Destoner, and Afterburner
Drum Motor
Individual, heavy duty gear motor. frequency inverter for speed control
Heating Source
Gas: L.P.G. / Natural Gas (40-120 kw) fully modulated burner
Cooling Blower
Powerful VoluMax Cooling, 3 hp, 3-4 minutes
Chaff Evacuation
Cyclone chaff collector - chaff compacting device optional
Door Opening
All machine door openings are actuated pneumatically. Drum gate is hinged with oil free bearings
Dimensions
269W x 333D x 281H cm (106" x 131" x 111")
Weight
1500 kg (3305 lbs)
Body
Full fairing covered, low profile structure, built in fork lift positioning tunnels. Full precision metal work, top quality hardware, galvanized steel, carbon steel and stainless steel
What is the batch capacity range of the Ghibli R90?
The Ghibli R90 is a powerhouse industrial roaster with a batch capacity of 30–90 kg (66–199 lb). Engineered for high-volume environments, it can comfortably produce up to 270 kg per hour, providing a complete industrial solution with precision and repeatability found in smaller specialty roasters.
Who is the Ghibli R90 designed for?
This model is built for industrial coffee producers and wholesale roasteries that operate on a massive scale. It is designed for those who require a "workhorse" yet want the best cup quality possible, with the highest levels of extractable properties in the coffee, while lowering energy consumption greatly.
What industrial-scale smoke solutions are available?
For the R90, we offer our high-capacity Industrial Afterburner, a direct-fired thermal oxidizer designed to handle the significant emissions of a 90 kg batch. It ensures your facility remains compliant with the strictest environmental regulations by eliminating smoke and odors.
How does the Ghibli R90 handle the physical workload of 90 kg batches?
To ensure efficiency and operator convince, the R90 features two large touch screens, a fully automated system. This includes an integrated pneumatic green bean loader with built-in scale and pneumatically actuated doors for the drum and cooling tray, allowing the roastmaster to manage the entire process through the digital control panel with minimal manual labor.
How does the R90 maintain precision at such a large scale?
The R90 utilizes a dual-stage modulated turbo gas burner (40-120 kw) and a sub-atmospheric combustion chamber. This setup provides a full range of heat modulation and isolates the drum from external atmospheric pressure and humidity, ensuring that even a 90 kg batch is roasted with the same accuracy as a laboratory sample roaster.
What is the "Volumax" cooling system?
At this scale, cooling the roast instantly is critical. The Volumax cooling group uses a high-capacity 3 HP suction blower and Teflon agitation blades to cool a full 90 kg batch in under 4 minutes. This immediate thermal drop locks in the flavor profile and prevents the "baked" taste associated with slow-cooling industrial batches.
How does the drum design support industrial consistency?
The R90 features our Vortex TO4 aerodynamic drum and a thermodynamic structure. This ensures perfect heat dispersion across the massive bean mass, while individual frequency inverters for the drum and airflow allow the roastmaster to fine-tune the roast.
What safety systems are built into this industrial model?
The R90 is equipped with a comprehensive safety suite, including a live waterline in-drum fire extinguisher, a secondary extinguisher in the chimney, and an emergency manual crank. The system also features a full fairing and low-profile structure to protect operators from high-heat surfaces and moving parts.
How are high-volume production logs and updates managed?
The R90 is fully automated via our proprietary PC-operated roasting software, which supports Wi-Fi updates. Additionally, it is compatible with all popular 3rd party roasting softwares
What are the primary maintenance requirements for the R90?
Despite its size, the R90 is designed for ease of maintenance. It features oil-free bearings on the drum gate, easy-access cleaning doors for the cooling group, and a dedicated cyclone chaff collector with an optional chaff compacting device to minimize downtime and cleaning intervals.
Is the Ghibli R90 built for 24/7 operation?
Yes. Every component—from the heavy-duty gear motors to the precision metalwork—is selected for extreme durability. The R90 is an industrial investment built to last decades, supported by a global network of distributors and long-term parts availability from Coffee-Tech Engineering.
