The Ghibli R90 ensures efficiency, reliability, and consistency. Aiming to maximize your coffee's flavor and aroma while optimizing extractable properties. This advanced roaster uses our in-house exclusive, technology to save energy and reduce your gas emissions. We made the perfect roaster for your industrial coffee business needs.
Swift, responsive pneumatic doors quickly load the drum or release the roasted beans.
Precisely monitor in-drum pressure to ensure consistent results and smooth operation.
Built with precision metalwork, and premium hardware for best reliability.
Safe manual drum rotation during power shortages
Necessary safety measure in an extreme event of fire inside the drum.
Intuitive touch screen interface for smooth, responsive control
Precise Green Coffee Loader with a built-in scale
Multi method cooling system for quick and uniform cooling
The Ghibli R90 is engineered for uncompromising precision and repeatability at an industrial scale. Designed for continuous, high-volume production, the R90 ensures that once a profile is set, it is reproduced with absolute accuracy across every shift. Consistency is achieved through an advanced industrial control system combining a sub-atmospheric combustion chamber, highly controlled airflow, precise thermal management, and continuous monitoring of all critical parameters. By fully isolating the roasting process from external environmental fluctuations, the Ghibli R90 delivers a level of industrial consistency that serves as the gold standard for large-scale coffee production.
The Ghibli R90 provides plant operators with absolute control over the immense thermal energy required for 90kg batches. Heat input, airflow, and drum speed are fully modulated from 0 to 100 percent, allowing for precise micro-adjustments in real time despite the scale of the machinery. Every parameter is clearly displayed and continuously monitored via an industrial-grade interface, giving the operator complete visibility and confidence. This level of control allows for the sophisticated shaping of flavor profiles with the reliability and freedom required by modern industrial roasteries.
Our latest-generation burners represent the highest standard achieved in the industry and are designed and used exclusively by Coffee-Tech Engineering. Advanced pre-mix technology distributes the air–fuel mixture evenly across a massive screened surface, creating a stable, predictable flame capable of heating 90kg of green coffee efficiently. This eliminates uneven flame peaks, ensures complete combustion, and significantly reduces NOx and CO₂ emissions. This precise, repeatable heat allows for uninterrupted production cycles and makes complex industrial profiles easier to reproduce consistently.
The Ghibli R90 features a heavy-duty ceramic-lined drum housing that insulates the massive roasting chamber, maintaining stable, evenly distributed heat throughout the roast. The thick ceramic layer shields the drum from external temperature influence, guaranteeing thermal stability even during back-to-back industrial cycles. This superior insulation significantly reduces heat loss and prevents constant reheating, dramatically lowering gas consumption and optimizing energy efficiency for high-output facilities.
Our geometric drum design was engineered in-house to manage the physics of a 90kg batch, maximizing contact between each bean and the drum surface to promote uniform heat transfer. This precise bean movement results in highly uniform development and repeatable outcomes across the entire mass. At the end of the roast, the specialized geometry enables rapid and complete evacuation of the full 90kg load, preventing over-roasting and ensuring the coffee stops developing exactly at the target point.
The Ghibli R90 is equipped with an industrial-strength turbo cooling system capable of cooling a full 90 kg batch in less than three minutes. Rapid cooling is critical at this scale to immediately stop the roasting process, preventing heat creep and locking in the intended flavor profile. The result is cleaner cup expression, higher consistency, and total control over the final roast outcome for high-volume commercial production.
Our Vortex drum utilizes an advanced spiral airflow pattern designed to drive heat through a massive bean mass in a controlled, continuous motion. This optimized airflow achieves superior heat transfer with less intake air, increasing plant efficiency while maintaining full control over the roast environment. The result is perfectly even bean development, improved energy efficiency, and consistently higher cup quality at an industrial scale.
The Ghibli R90 supports fully integrated industrial smokeless solutions, engineered to meet the strictest environmental regulations for large-scale manufacturing. Our high-capacity Afterburners eliminate smoke and emissions through high-temperature combustion, effectively neutralizing CO, NOx, SOx, and other pollutants. These systems are highly efficient, reliable, and purpose-built to handle the heavy exhaust loads of the R90, ensuring your industrial facility operates cleanly and responsibly.
Record and analyze your industrial roasting data with ease. The Ghibli R90 is fully compatible with all popular roast logging and plant management software, ensuring your production data is always integrated.
Regular software updates are developed by our team and can be deployed via Wi-Fi, allowing even established Ghibli R90 installations to benefit from the latest improvements, safety protocols, and efficiency features.
Despite its massive 90kg capacity, the Ghibli R90 features a remarkably efficient footprint. It is the most compact and space-efficient industrial roaster in its class, allowing you to maximize your production floor's output without requiring the sprawling square footage of traditional industrial machines.
Backed by an experienced technical team and a global network of authorized distributors, the Ghibli R90 is supported with prioritized industrial after-sales service, expert technical guidance, and long-term parts availability. With three decades of experience building top-quality coffee roasters, Coffee-Tech Engineering is the industrial partner you can rely on for uninterrupted production.
Built with reinforced premium materials and industrial-grade components, the Ghibli R90 is engineered for 24/7 durability and long-term reliability. The Ghibli series has continuously evolved over the decades, with our earliest industrial machines still serving as the backbone of roasteries around the world today.
Bean, drum, and exhaust temperatures are continuously monitored with three high-precision integrated probes, ensuring the thermal control and high repeatability required for professional industrial quality assurance.
The Ghibli R90 is built with a reinforced, sealed structure that prevents industrial emissions from escaping, ensuring a safe working environment. An integrated in-drum fire extinguisher allows for immediate response, while a manual safety crank enables the operator to evacuate the 90kg load manually in the event of a power loss. At Coffee-Tech Engineering, safety is engineered with responsibility and intention, because protecting your facility and staff is as critical as protecting the roast.
Perfect heat dispersion assures essential coffee compounds are fully developed and enhanced during the roasting process.
A unique combination of conduction and controlled convection assures the final cup profile displays excellent, high aroma levels.
Advanced thermodynamic design and a clean, precise combustion method secure a high-quality, smooth cup profile.
Engineered for high-output performance with minimal power consumption, ensuring maximum energy savings and a reduced carbon footprint.
Batch Capacity
30 - 90 kg (66 - 199 lbs) of Green Coffee
Roasting Cycle
16-18 minutes for a full batch
Hourly Output
Approx. 270kg (595 lbs)
Quality and safety compliance
CE, RoHS, EMC
Electrical Specifications
3x230/3x110V | 11,000W | incl. Loader, Destoner, and Afterburner
Drum Motor
Individual, heavy duty gear motor. frequency inverter for speed control
Heating Source
Gas: L.P.G. / Natural Gas (40-120 kw) fully modulated burner
Cooling Blower
Powerful VoluMax Cooling, 3 hp, 3-4 minutes
Chaff Evacuation
Cyclone chaff collector - chaff compacting device optional
Door Opening
All machine door openings are actuated pneumatically. Drum gate is hinged with oil free bearings
Dimensions
269W x 333D x 281H cm (106" x 131" x 111")
Weight
1500 kg (3305 lbs)
Body
Full fairing covered, low profile structure, built in fork lift positioning tunnels. Full precision metal work, top quality hardware, galvanized steel, carbon steel and stainless steel
What is the batch capacity range of the Ghibli R90?
The Ghibli R90 is a powerhouse industrial roaster with a batch capacity of 30–90 kg (66–199 lb). Engineered for high-volume environments, it can comfortably produce up to 270 kg per hour, providing a complete industrial solution with precision and repeatability found in smaller specialty roasters.
Who is the Ghibli R90 designed for?
This model is built for industrial coffee producers and wholesale roasteries that operate on a massive scale. It is designed for those who require a "workhorse" yet want the best cup quality possible, with the highest levels of extractable properties in the coffee, while lowering energy consumption greatly.
What industrial-scale smoke solutions are available?
For the R90, we offer our high-capacity Industrial Afterburner, a direct-fired thermal oxidizer designed to handle the significant emissions of a 90 kg batch. It ensures your facility remains compliant with the strictest environmental regulations by eliminating smoke and odors.
How does the Ghibli R90 handle the physical workload of 90 kg batches?
To ensure efficiency and operator convince, the R90 features two large touch screens, a fully automated system. This includes an integrated pneumatic green bean loader with built-in scale and pneumatically actuated doors for the drum and cooling tray, allowing the roastmaster to manage the entire process through the digital control panel with minimal manual labor.
How does the R90 maintain precision at such a large scale?
The R90 utilizes a dual-stage modulated turbo gas burner (40-120 kw) and a sub-atmospheric combustion chamber. This setup provides a full range of heat modulation and isolates the drum from external atmospheric pressure and humidity, ensuring that even a 90 kg batch is roasted with the same accuracy as a laboratory sample roaster.
What is the "Volumax" cooling system?
At this scale, cooling the roast instantly is critical. The Volumax cooling group uses a high-capacity 3 HP suction blower and Teflon agitation blades to cool a full 90 kg batch in under 4 minutes. This immediate thermal drop locks in the flavor profile and prevents the "baked" taste associated with slow-cooling industrial batches.
How does the drum design support industrial consistency?
The R90 features our Vortex TO4 aerodynamic drum and a thermodynamic structure. This ensures perfect heat dispersion across the massive bean mass, while individual frequency inverters for the drum and airflow allow the roastmaster to fine-tune the roast.
What safety systems are built into this industrial model?
The R90 is equipped with a comprehensive safety suite, including a live waterline in-drum fire extinguisher, a secondary extinguisher in the chimney, and an emergency manual crank. The system also features a full fairing and low-profile structure to protect operators from high-heat surfaces and moving parts.
How are high-volume production logs and updates managed?
The R90 is fully automated via our proprietary PC-operated roasting software, which supports Wi-Fi updates. Additionally, it is compatible with all popular 3rd party roasting softwares
What are the primary maintenance requirements for the R90?
Despite its size, the R90 is designed for ease of maintenance. It features oil-free bearings on the drum gate, easy-access cleaning doors for the cooling group, and a dedicated cyclone chaff collector with an optional chaff compacting device to minimize downtime and cleaning intervals.
Is the Ghibli R90 built for 24/7 operation?
Yes. Every component—from the heavy-duty gear motors to the precision metalwork—is selected for extreme durability. The R90 is an industrial investment built to last decades, supported by a global network of distributors and long-term parts availability from Coffee-Tech Engineering.
